RF power supply connector cable assy G8010-60801 If not voltages reported then RFPS or MPM are faulty, or there is an interlock problem, or connection for the RFPS is faulty. 50v on the left side and ( with the cable disconnected) approx. If this happens look at the voltage on the diagnostics, it should be approx. can you see the RFPS power on and the fans start to rotate? Can you hear the relay click in the MPM?ī. (2 pin Red/Grey wires connector, lower connector on the RF filter board on the rear, this is the RFPS feed up to the SSRF)ģ.Ensure interlocks are satisfied (RF door closed)Ĥ.Set 50V and 150V RF power supply (click twice to get to 150V) on Diagnostics > Instrument > Plasma sectionĪ. If NO voltage is observed then isolate the RF power supply and SSRF following next steps:Ģ.Disconnect RF power cable from Filter board. Test RF Power supply to 150V from diagnostics (remember first click gives 50V and then another click gives 150V). More information on reactions in source for methane CI reagent.

AGILENT CHEMSTATION ERROR CODES MANUAL

Go to manual tune and manually change all quad parameters you have a working EI tune for. Corrupt tune file - reload a default pcich4.u tune from the mssetup directory.make sure the Tip seal and spring are correctly installed. Seal between the transfer line and the ion source.Below is more detailed list of possible problems. The usual culprit is the seal between the transfer line and the ion source. If the system can not reach a target of 2.2-2.3 more then likely there is a leak somewhere. The ratio of the intensity of Mass 28 / Mass 27 is used to adjust the correct pressure in the trap. (See below for complete list of reactions that occur with methane in the source). The system is looking for a target ration of m/z 28 and m/z 27. The methane flow adjument fails and autotune can not be started.īefore the CI autotune is performed, the system will optimize the flow of methane into the source to adjust the pressure to the optimum level. To automate the file transfer, edit your MH GCMS Acquisition Method and add the followingĬommand in the Method Information Post-Run Macro/Command field:

AGILENT CHEMSTATION ERROR CODES PC

This allows multiple instruments on the same PC to send data to unique locations. masshunter\gcms\x where x=instrument number). Nas_copy.ini, located in the instrument folder (i.e. The configuration information is stored in the file Will allow multiple instruments to share the same drive and store the data in From the command line in MH GCMS Acquisition, type the following:įollow the prompts on the screen to select the destination for data files. !directories have been created, use the ConfigCopy macro to select them for use The configuration process will allow destination selection.

The remote file system MUST have directories created for the file transfer before Of exporting data files (and associated directory structure) acquired onĪgilent MassHunter GCMS Acquisition platforms to networked or secondary drives. "nas_copy.mac" is a CONTRIBUTED UTILITY to be used for the purpose

AGILENT CHEMSTATION ERROR CODES DRIVER

To setup post run file copy you can use a macro called "nas_copy.mac" to copy the file from the local drive to network driver AFTER the data is collected. The preferred way is to complete this task is to collect the data on the local file system and then copy to the network location after the run completes.

AGILENT CHEMSTATION ERROR CODES SOFTWARE

Network hardware or software the raw data can be lost. Collecting data to a network drive is usually not a good idea if any issues arise with the Many customer's have the need to collect data directly to a network drive.
